Dust-tight drum tipper introduced
A drum tipper designed for use with poorly flowing or agglomerated materials has been introduced.
The drum tipper allows for dust-free, rapid transfer of free- and non-free-flowing bulk solid materials.
Flexicon’s TIP-TITE drum tipper is similar in performance to open chute tippers but with total dust containment. The outlet on the downstream end of the tipper is nearly equal in area to that of the drum opening, allowing agglomerated materials and large chunks to be discharged with the minimal possibility of material bridging.
Drums from 114 ℓ to 208 ℓ are positioned on the tipper platform, which is raised by a hydraulic cylinder, seating the rim against the circular end of the discharge transition. A second hydraulic cylinder tips the platform-hood assembly and drum, stopping at dump angles of 45°, 60° or 90° with a motion-dampening feature. At full rotation, the transition outlet mates with the gasketed square inlet on the lid of a hopper or downstream process equipment, allowing a pneumatically-actuated slide gate valve to be opened and closed for total or partial discharge with no dusting.
The stainless steel transition can be supplied with a square, rectangular or circular outlet, with corresponding gasketed flanges for installation on downstream hoppers and receiving vessels.
Non-product-contact materials of construction can be specified in carbon steel with durable industrial finishes, or stainless steel finished to industrial or sanitary standards.
Additional models are available for the dumping of boxes, bins, pails and other containers.
